Belting Technical Data Sheets

Photo Name Part Number Technical Data
02 305 Sno Cone Sno Cone

Excellent oil and grease resistance. Very good resistance to acids and solvents but avoid high concentrations. Ozone resistant. Small, white highly oil resistant pyramids firmly hold a variety of products with multiple contact points. FDA approved for handling baked goods, packaged meats and bags of granular materials.

02-305 Download
03 123 Spab Wu 200 SPAB WU 200

Belt has lower stretch factor and is more sanitary than cotton belts; baking: dough transfer, Stickleber straightaway molder/panner, pressure board and bagel formers.

03-123 Download
03 707 Spab Wu 300 SPAB WU 300

Belt has lower stretch factor and is more sanitary than cotton belts. Bakery applications include Bagel formers and moulders and panners

03-707 Download
04 708 Sparlon 15 P Sparlon 15P

Paper handling belt, Processing belt. Suitable for power transmission and spindle drives, in these applications the black side is the spindle side. Maximum tensile load is 350 N/m belt width.

04-708 Download
04 709 Sparlon 1 P Sparlon 1P

Suitable for paper transport, light weight power transmission and other specialty applications. .6 to 3% recommended elongation at the time of installation.

04-709 Download
04 700 Sparlon 3 E Qm Grey Sparlon 3E QM Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. The quick finger splice is ideal for applications where downtime must be kept to an absolute minimum. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing industry and tube winder applications in the corrugated industry. Commonly used on Flexo Folder Gluers.

04-700 Download
04 704 Sparlon 3 P Grey Sparlon 3P Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing graphic industry and tube winder applications.

04-704 Download
04 701 Sparlon 4 E Qm Grey Sparlon 4E QM Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. The quick finger splice is ideal for applications where downtime must be kept to an absolute minimum. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing industry and tube winder applications in the corrugated industry. Commonly used on Flexo Folder Gluers.

04-701 Download
04 705 Sparlon 4 P Grey Sparlon 4P Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing graphic industry and tube winder applications.

04-705 Download
Sparlon 5 E Qm Grey Sparlon 5E QM Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. The quick finger splice is ideal for applications where downtime must be kept to an absolute minimum. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing industry and tube winder applications in the corrugated industry. Commonly used on Flexo Folder Gluers.

04-702 Download
04 706 Sparlon 5 P Grey Sparlon 5P Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing graphic industry and tube winder applications.

04-706 Download
04 703 Sparlon 5 E Qm Grey Sparlon 6E QM Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. The quick finger splice is ideal for applications where downtime must be kept to an absolute minimum. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing industry and tube winder applications in the corrugated industry. Commonly used on Flexo Folder Gluers.

4-703 Download
04 707 Sparlon 6 P Grey Sparlon 6P Grey

Excellent resistance to oils, inks, chemicals and abrasion. This belt is non-marking, offers permanent antistatic characteristics and provides high flexibility and dimensional stability. Ideal for folder gluer machines and production lines in the corrugated industry. Also suited for printing graphic industry and tube winder applications.

04-707 Download
Spm SPM 3.19

The Dura-Drive Synchronous motorized pulleys are high powered, high-efficiency motors that help lower energy costs by running more efficiently and in turn, meeting current energy efficiency regulations. The permanent magnet design is the key to the high efficiency and the power density. Best for applications in logistics, general automation, machine building, and are especially suited for servo-type applications.

SPM 3.19 Download
Spm SPM 4.39

The Dura-Drive Synchronous motorized pulleys are high powered, high-efficiency motors that help lower energy costs by running more efficiently and in turn, meeting current energy efficiency regulations. The permanent magnet design is the key to the high efficiency and the power density. Best for applications in logistics, general automation, machine building, and are especially suited for servo-type applications.

SPM 4.39 Download
02 425 Sr 25 SR-25

Limited oil, grease, acid and solvent resistance. Very good resistance to wide temperature ranges. This belt is both thin and strong. Ideal for heat sealing machines, shrink tunnels, automatic weighing and feed conveyors. The silicone compound has excellent release properties. For laced belts, use 1" minimum pulley diameter. Do not use on conveyors having crowned pulleys as the fiberglass will not stretch to conform.

02-425 Download
07 000 Coil Wrapper Belt Standard Duty Coil Wrapper 07-000 Download
02 050 Tev Tex 22 M Tev Tex 22 M

Excellent oil and grease resistance. Very good resistance to acids and solvents but avoid high concentrations. Ozone resistant. Teflon cover offer superior release and easy cleaning on products like glue, marshmallows, candy, chemicals and hot plastics. Preferred choice on case sealer "top impression" belts. Stain resistant. DO NOT USE on conveyors with scrappers or where pulleys cause belt to severely back-bend.

02-050 Download
02 051 Tev Tex 32 M Tev Tex 32 M

Excellent oil and grease resistance. Very good resistance to acids and solvents, but avoid high concentrations. Ozone resistant. Teflon cover offer superior release and easy cleaning on products like glue, marshmallows, candy, chemicals and hot plastics. Preferred choice on case-sealer top impression belts. Do not use on conveyors with scrapers or where pulleys cause belt to severely backbend.

02-051 Download
02 011 Thermoflex 2100 White Thermoflex 2100 White

Very good resistance to animal fats, vegetable and mineral oils. Good resistance to acids and solvents, but avoid high concentrations. Excellent combination of bulk/durability (like "rubber" belts) and superior fabrication features (like "ultraline" belts). Suited for handling meat, poultry, fruits, nuts, vegetables or plastics.

02-011 Download
